HG-SR502 Servo Motor
Servo motor HG Series, Power 5 kW; Torque 23.9 Nm, Max. Torque 71.6 Nm
Description
Mitsubishi HG-SR502 Series Servo Motor
| Type | HG-SR |
| Rated Capacity (kW) | 5 |
| Rated Torque (Nm) | 23,9 |
| Maximum Torque (Nm) | 71,6 |
| Rated Speed (rpm) | 2000 |
| Maximum Speed (m/s) | 3000 |
| Inertia (kg*cm2) | 99,7 |
| Brake | NO |
| Shaft Type | STRAIGHT SHAFT |
| Protection Class | IP67 |
| Power Supply (V) | 200 |
| Current Type | AC |
| Encoder Type | ABSOLUTE/INCREMENTAL |
| Encoder Resolution (p/rev) | 4194304 |
